P 05 511

Technical data

Thread G 1/8"

Nominal width [mm] 6

flow [l/min] 750

Resetting spring

Working pressure [bar] 0 - 10

Control pressure* [bar] 3 - 10

Control connection 14 G 1/8"

Note RoHs-compliant

Weight 200 g / pc.

Further information

GTIN 4050571537951

Customs duty number: 84812090

Description

Materials:

Body: anodized aluminium, internal parts: aluminium, brass and stainless steel, seals: plastic and NBR

Temperature range:

-10°C to max. +70°C

Media:

oiled and unoiled filtered compressed air

ATEX:

available with ATEX approval Ex II 2GD c T5 T100°C, Tmedium / Tamb: -10°C to +50°C max., see the operating instructions for full details

Pressure input:

Connection 1

Optional:

ATEX authorization EX <b style="box-sizing: border-box; margin: 0px; padding: 0px; border: 0px;
